Characteristic:
& Middot; All-weather environmental design, high-strength aluminum alloy precision casting shell, impact resistance, corrosion resistance, protection level up to IP66
& Middot; strong protection capability, IP66; high-end motor, good stability, low noise; high-strength aluminum alloy precision casting shell, strong wind resistance, smooth operation, ensure accurate positioning
& Middot; Laser night vision distance greater than 200 meters, camera night vision up to 1000 meters (with different cameras)
& Middot; Real-time processing of lens focal length information, laser illumination spot can automatically zoom with the lens synchronously, but also independently and remotely adjust. Synchronization between the preset position of the platform and the size of the laser spot
& Middot; Laser brightness can be manually adjusted according to night illumination.
& middot; laser spot angle 0.2 & deg; ~30 & deg;, convenient for users to monitor night vision far and near
& middot; using the imported array laser from the United States to eliminate laser speckles and maximize the effect of homogenization
& Middot; no dead angle, 360 & deg; continuous operation, built-in intelligent speed change decoder, ultra wide speed range 0 & deg; ~40 & deg; /S
& Middot; 6 patrol trajectories, 128 presets to capture targets in the shortest possible way
& Middot; protective cover with automatic heating system, with defrosting, wiper function, users can configure 20, 30 times high focal length lens to achieve telescope monitoring
& Middot; Wide-angle high-speed, telescope slow, fast and convenient target capture
Ball machine performance:
control mode |
RS485, built-in 16 protocols, baud rate from 2400 Bps to 1200 Bps optional |
Horizontal Manual Control Speed |
0°—40°/S |
Vertical Manual Control Speed |
0°—5°/S |
Horizontal angle |
360°continuously |
Vertical angle |
+90 ~ -40° |
Preset |
128(Max) |
control mode |
Multi-protocol,RS485 |
relative humidity |
98% |
Protection Level |
IP66 |
working temperature |
-35℃—+55℃ |
Power Consumption of Power Supply |
AC24V±10% （50VA） |
Impact Resistance Requirements |
≥4G |
Reset |
15Kg |
Maximum size of camera and lens |
280*125*104mm (including BNC plugs) |
| length | 582mm |
